| | | PElectro wia, est un logiciel d'électronique. Il permet de concevoir les circuits électroniques et de les tester. Il est interfacable avec les logiciels suivants: - CiDess pour la partie PCB, - Avec d'autres simulateurs acceptant les Netlists. |
|
| |
| | |
| | |
| | Circuits réalisés avec PElectro wia |
|
| | | | Exemples de circuits réalisés avec PElectro wia. A mettre dans le répertoire Examples de l'installation. |
| |
| |
| | |
| | |
| | Composants à ajouter à PElectro wia |
|
| | | Composants à ajouter pour étendre les éléments disponibles dans PElectro wia. |
|
| |
| | |
| | |
| | | | Aides de PElectro wia et de ses possibilités. |
| |
| |
| | |
| | | | Les améliorations des dernières versions |
| |
| | | 6.2.1.1437 win32 or 6.2.1.1455 win64
Fixed bugs and add:
It's PElectro preview programme,
PElectro.exe
From 11 december 2025
-Improvements and bug fixes in subct management.
If you have passed subckts into the application, you
must reassign them and restart the Subckt->PElectro
procedure in the Plugins menu. To reassign the subckts,
copy them to the ImExport directory under
Documents\PElectro.
From 9 december 2025
1) Improved PCB vias.
2) Added the concept of Blind and Buried vias, with
Blind via selection in the options.
From 7 december 2025
1) Improved PCB manufacturing (particularly for mass
production).
2) Improved label display when the language changes.
From 3 december 2025
1) Improved management of help in French
2) Better managed help display selection
From 17 november 2025
1) Complete correction of digital components:
For each existing circuit, launch the "Recalculate Schematic"
function from the Edit menu. Then check in the Values field
to ensure everything is displayed correctly
(especially the component terminals). Finally, test
the circuit to verify everything is working correctly.
2) Shortcuts usable in PElectro are located in a
tab within the main PElectro window. This allows you,
for example, to find how to activate a previously
saved list of actions.
From 05 november 2025
1) Launching external SUBCKT files to PElectro,
and from PElectro to LTSpice.
-PElectro to LTSpice:
A) First, launch the PElectro->LTSpice process if
the link has been established.
B) At the end, in the general settings, launch
the LTSpice option and then confirm.
C) Now, PElectro subckt can be used in the
LTSpice application, and the PElectro->LTSpice File
function can be selected to convert PElectro circuits
within the LTSpice application.
-Other Application to PElectro:
A) Copy the subckt files to the ImExport directory
of the PElectro documents (in Documents).
B) In the Subckt Library, choose the symbol type
and the links between components and symbols.
Confirm and restart PElectro-wia.
C) The subckt files are now usable in the application.
For LTSpice, step B) is not necessary, in the general
settings, reactivate LTSpice by confirming the window.
2) Fixed display issues on the generated PCB's Gerber files.
3) Corrected the PCB layout and schematic during printing.
4) correction of a problem on the conversion of subckt to
PElectro at the node level.From 30 october 2025
From 30 october 2025
1) Fixed AmpOp in examples, Run LTSpice
parameters in PElectro
From 28 october 2025
1) Fixed a transparent symbol in the middle following an error.
2) Added the symbol grouping function to the plugin menu.
3) Fixed the symbol spacing during the symbol spacing function.
From 25 october 2025
1) Fixed an error in the rectangle routine.
2) Added refresh in the LTSpice and CiDess parameters for the PElectro symbol.
3) Fixed a bug in the CiDess symbol handling.
From 23 october 2025
Fixed digital component links.
From october 2025
1) The New commands .SUBCKT, .PARAM, .FUNC, .TEXT, .STEP and other.
2) Read LTSpice file.
3) Noise and Monte-carlo simulations.
4) Strap, OTA, RON and ROFF Diode, "B", POLY, and other components.
5) Space between components in layout.
6) New languages.
7) Calculator in folder PElectro.
8) Insertion Saisie.exe in PElectro.
9) Fast run at lauch.
10) Digital add.
11) Compatibility with spice, LTSpice, PSpice.
12) Recovery program CDL, CDP and layout old version.
13) Compatibility with Librarian and LTSpice symbol.
14) and other.
15) The use of global links between PElectro and CiDess or LTSpice
which allows you to choose parameters such as the angle, the
organization of the terminals of the boxes is now possible.
Jean Barreau
5.0.2.0715
Fixed bugs:
Saisies.exe
PElectro.exe
1) improvement PWL voltage and current sources.
2) in PElectro routing with Cidess software.
3) in inversion of arc picture.
4) improvement of CAUER's filter.
5) add mil measure in numeric value.
6) add pourcent (%) in numeric value.
7) improvement RCE in transistor.
8) in printing diagrams.
Jean Barreau
5.0.1.0628
Fixed bugs:
Saisies.exe
PElectro.exe
1) improvement measures instrument.
2) fixed bug AOP in 5.0.1.0578 version.
Jean Barreau
5.0.1.0578
Fixed bugs:
Saisies.exe
PElectro.exe
1) correction of field usable in component
library badly defined.
2) improved frequency display in simulation.
3) special case addition to the cauer filter.
Jean Barreau
5.0.1.0574
Fixed bugs:
Saisies.exe
PElectro.exe
1) Fixed bug in A-1 matrix,
2) Fixed bug in managing the ImageUser.txt
file,
3) Separation of user and system symbols
files in CDL and CDP, allready the
system symbols file is put in install,
it shall stay user file on the disk,
4) Ergonomic improvement of
copy/selection paste. Paste immediately
under the mouse. For the following do
edit/paste layout,
5) Improvement, no Laplace function with
polarization simulation,
6) Add shortcut, example Ctrl-T for temporal
field,
7) Improvement memory leak,
8) Improvement test bench in double click on
row of table plugins, especially for transistors
and mos,
9) Fixed bug in diagrams listview click,
10) Fixed bug Russian language message scheduling,
11) Improvement transistors functions,
12) fixed bug omission of the real and imaginary
part with zeros in the phase calculation,
13) Download a .zip instead of an .exe for new
versions,
Jean Barreau
5.0.1.0477
Fixed bugs:
Saisies.exe
PElectro.exe
1) Improved frequency response,
2) improvement of simulation matrices,
3) Fixed bug in filter,
4) Fixed bug in the representation
of numbers,
5) Component size estimate error in
export to CiDess,
6) Improvement of PElectro and CiDess
routing,
7) Improvement of CAUER's filter,
Jean Barreau
5.0.1.0426
Fixed bugs:
Saisies.exe
PElectro.exe
1) improvement of the CDP display tab,
2) PElectro is downloaded in the local download
directory,
3) Improved removal of a node,
4) PWL, PULSE, EXP and others display timing
error with only negative values,
5) Reverse VDS with JFET and MOS components,
6) CMOS operation correction in linearization,
7) Error in ground NETLIST,
8) Error on click to the right of the
voltage / current source curve of the
independent source window,
9) Add LTSpice PHI parameter of EXP in read file,
10) Error with PULSE function,
11) Modify ComboBox Change event in voltage / current
source,
12) Error PULSE, EXP, SIN, SFFM in read file,
13) Add LTSPICE SINE function,
5.0.1.0377
Fixed bugs:
Saisies.exe
PElectro.exe
1) Error in radio button Potentiometers (simulator)
2) Error write for Text and JPEG file on disk,
3) Error in AOP simulation with offset adjusted,
4) An improvement in SYSLIN function of Newton simulation,
5) taking into account the resistance of the AOP
in the linear simulation,
6) phase correction of controlled sources,
7) Bug with mains voltage and frequency,
8) Another bugs.
5.0.1.0288
Fixed bugs:
Saisies.exe
PElectro.exe
1) Zener voltage curve error,
2) Photodiode current curve error,
3) Error varistor in linear simulation,
4) Error polarization of switch RT,
5) Update netlist management,
6) Error char µ (micron) with
unit A(Amp),F(Farad),M(meter),
7) Error when PElectro and CIDESS are
not in the same disk
(for Read CIDESS file).
|
| |
|
| |
| |
| | | |
